BUILD KIT

• FRAME Orbea Urrun, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148×12, carrier and kickstand compatible
• FORK Fox 34 Float Performance 120 Grip 3-Position QR15x110 E-Bike Optimized
• HEADSET FSA 1-1/2″ Integrated Aluminium Cup
• CHAINRING Alloy EP8 32t
• CRANK Shimano Steps EM600
• SHIFTERS Shimano XT M8100
• CASSETTE Shimano CS-M7100 10-51t 12-Speed
• REAR DERAILLEUR Shimano XT M8100 SGS Shadow Plus
• CHAIN Shimano M6100
• CHAINGUIDE Orbea Rise chainguide
• HANDLEBAR OC Mountain Control MC31, Rise20, Width 800
• STEM Alloy forged, 35mm interface, -6, ICR
• BRAKES Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
• WHEELS Alloy, Tubeless, 29″, 29c, 32H
• TYRES Schwalbe Wicked Will Evo TLE, 29×2.40 Super Race, Speed Grip, Addix, Brown
• PEDALS VP-537 Black
• SEATPOST OC Mountain Control MC21, 31.6mm, Dropper
• SEATPOST LEVER Shimano SL-MT500
• SADDLE Selle Royal Vivo Sport Men 145 x 269mm
• MOTOR Shimano EP801-RS
• BATTERY Orbea Internal 540Wh (Optional 250 Wh Range Extender)
• RANGE EXTENDER N/A
• DISPLAY Shimano EN600
• CHARGER Orbea 2.Generation eBike Smart charger 42V/2-4A
• REMOTE EN600-L

SIZING: Orbea recommends the following sizes based on rider height:

• SM: 5′ 1″ – 5′ 7″
• MD: 5′ 5″ – 5′ 11″
• LG: 5′ 10″ – 6′ 3″
• XL: 6′ 1″ – 6′ 7″
