The Lowside is the bike that gets you across town for a quick rip on singletrack, then over to the bar for a night out. Its the bike you turn to when youre not entirely sure what the night has in store. Its the bike to grab when you want to have just much fun riding to the trail as you do from the trail itself. Singlespeeding is an integral part of Surlys DNA, and the Lowside continues the tradition, by taking a simpler approach to trail riding.

• 100% Surly 4130 Chromoly frame, main triangle is double-butted; 1-1/8″ threadless Chromoly fork
• Singlespeed specific (derailleur hanger but no Trip Guides)
• Dropper post routing
• Gnot-Boost rear spacing
• Front and rear thru-axle
• 26 x 3 or 27.5 x 2.8 tire clearance
• Complete Bike Weight: 31 lb. 6 oz. for Medium

BUILD KIT:

• Frame: Surly Lowside – 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
• Fork: Surly Lowside – 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
• Color: New Pig Smell
• Cog: Surly 17t w/ spacer kit
• Chain: KMC X10
• Crankset: SRAM NX 32t
• Bottom Bracket: SRAM Powerspline
• Brakes and Rotors: Tektro HD-M275 (Tektro HD-M276 on XS), Tektro 160/160, 6-Bolt
• Headset: Cane Creek
• Stem: Sunday Freeze Stem Top Load
• Handlebar: Surly Sunrise
• Grips / Bar Tape: Velo Black Lock-On
• Seatpost: Promax SP-2019, 0 Offset
• Saddle: WTB Volt
• Front Hub: Novatec 15 x 110mm, 6-bolt, 32h
• Rear Hub: Novatec 12 x 148mm, 6-bolt, 32h
• Rims: ALEX MD40 26″
• Tires: Surly Dirt Wizard 26 x 3″, 60tpi
• Spokes: 14G Black

SIZING: Surlyrecommends the following sizes based on rider height

• XS : 5′ – 5’5″
• SM : 5’4″ – 5’8″
• MD : 5’7″ – 6′
• LG : 5’11” – 6’3″
• XL : 6’2″ – 6’6″
